Application of fruit and vegetable drying machine:
1. Dry apple, lemon, mango slices, Longan and other fruits.
2. Dry radish, lettuce, pumpkin, carrot, spinach, cassava and other vegetables.
3. Dry meat, such as fish, sausage, ham, etc.
Drying capacity: 0.2 to 10 tons per day
Heat sources: electricity, coal, steam, natural gas, biomass pellets, diesel, methane, heavy oil, methanol, etc.
Introduction to fruit and vegetable dryer:
The heat pump fruit and vegetable drying machine room is a device that transfers heat from a colder area to a hotter area. It has the ability to recover latent and sensible heat through condensation. The heat pump fruit dryer machine room can dry efficiently even in humid environments, with low operating costs. The heat pump fruit and vegetable dryer machine works in controllable and constant temperature to ensure the color, fragrance and shape of fruit.
Application of heat pump fruit and vegetable drying room machine:
1. Dry apple, lemon, mango slices, Longan and other fruits.
2. Dry radish, lettuce, pumpkin, carrot, spinach, cassava and other vegetables.
3. Dry meat, such as fish, sausage, ham, etc.
Advantages of heat pump fruit and vegetable dryer machine room:
1. Compared with electric drying, the operating cost of the heat pump fruit dehydrator machine room can be saved more than 70%.
2. Different drying parameters can be set according to characteristics of different materials, and the heat pump fruit dryer machine room is especially suitable for drying heat sensitive materials such as fruits and vegetables.
3. The fruit heat pump drying machine room adopts drying technology of air energy heat pump, which is environmentally friendly, efficient and energy-saving, precise and intelligent.
4. The principle of our heat pump fruit dehydrator machine room is to dry the fruits in the drying room by absorbing the heat energy in the air. Therefore, the whole drying process will not produce any waste pollutants, which ensures the cleanness and sanitation of the dried fruits.
5. The application of the circulating fan system and the polyurethane insulation board room enables the heat generated by the heat pump host to be efficiently recycled in the heat pump fruit drying equipment room. The insulation board is with a very good airtight performance, so that the heat will not be lost.
6. The layer spacing of carts and pallets and mesh sizes are all designed in accordance with the drying needs of many customers, ensuring that all parts of the fruit are evenly heated during drying process, so that the shape, color and quality of dried fruit are all in desired effect.
Technical Data:
Model | GX-3P | GX-5P | GX-8P | GX-15P |
Heat Pump Size (L*W*H)mm | 1800*1000*1070 | 1800*1000*1070 | 1800*1000*1300 | 2150*1260*1620 |
Drying Room Size (L*W*H)mm | 3300*2000*2200 | 3300*2000*2200 | 5600*2200*2700 | 8000*3000*2850 |
Rated Heating Capacity (kw) | 10.75 | 12.25 | 23.2 | 49.65 |
Host Power(kw) | 2.5 | 4 | 7.2 | 13.9 |
Electric heating power(kw) | 6 | 6 | 12 | 24 |
Circulating fan power(kw) | 8 x 0.25 | 8 x 0.25 | 12 x 0.25 | 12 x 0.75 |
Returning Fan power(kw) | / | / | 3 x 0.25 | 3 x 0.75 |
Humidity exhausting fan(kw) | 1 x 0.25 | 1 x 0.25 | 1 x 0.25 | 2 x 0.25 |
trolley Qty | 4 | 4 | 6 | 15 |
trolley size(mm) | 810*860*1750 | 810*860*1750 | 880*1200*1750 | 880*1200*1750 |
tray Qty | 96 | 96 | 144 | 360 |
tray Size (mm) | 430*730 | 430*730 | 600*800 | 600*800 |
tray Material | PP Polypropylene/Stainless Steel |
